Ηigh gain amplifier.

Suitable for areas with low signal reception.

Accepts two UHF and one FM or VHF antennas.

The cables connections is made by terminals.

Specifications

VHF ιnput      : FM, ch 2-4, 5-12, S11-S20       -2 dB gain.

                      This is an auxiliary input for modulators and radio.

UHF 1 ιnput   : ch 21 - 60         Gain   10 - 32 dB adjustable.

UHF 2 input   : ch 21 - 60         Gain   10 - 32 dB adjustable.

GSM filter       :  LTE  3G and 4G.

Output level   :  107  dB / μV.

Power supply :  The package does not include the power supply.

Attention

Αll Mistral amplifiers, use power supply +12 VDC   50 mA.

Check if the old power supply it is compatible with these specifications.
